HANMI Semiconductor opened its U.S. subsidiary, HANMI USA, in San Jose, California, with an October 16 opening ceremony attended by Chairman Kwak Dong-shin and company executives. The company said the HANMI USA office will operate as an integrated hub serving U.S. semiconductor customers, with engineers providing technical support tied to ramp-ups at newly built U.S. fabs.
What it means
HANMI USA joins the company’s subsidiaries in Taiwan, China and Singapore. HANMI Semiconductor said the San Jose office will place experienced engineers locally to provide direct technical assistance and respond to customer demand.
The company supplies semiconductor packaging equipment to foundries and outsourced semiconductor assembly and test providers. Its equipment lineup includes three 2.5D TC bonders, two 2.5D FC bonders, the BOC COB Bonder and EMI Shield equipment.
Key facts
- HANMI Semiconductor held the HANMI USA opening ceremony in San Jose, California, on October 16.
- Chairman Kwak Dong-shin and company executives attended the event.
- HANMI USA will serve as an integrated operational hub in San Jose.
- HANMI Semiconductor said it holds the No. 1 global market share in TC bonders used in HBM manufacturing.
- The company said it is also the No. 1 supplier of micro SAW & VISION PLACEMENT equipment.
- HANMI Semiconductor was founded in Korea in 1980.
- The company operates subsidiaries in Taiwan, China, Singapore and the United States.
Source: HANMI Semiconductor announcement
